AT (Acoustic/Thermal) Panel
Key Differentiators
- Engineered and verified construction to ensure acoustical, thermal, and structural performance
- Many thickness and material options to fit most applications
- Experienced design assistance available for tough projects
Product Details
| Applications | Casinos, Clean Rooms, Data Centers, Education, Government, Healthcare, Hospitality, Labs, Office and Commercial, Pharma |
|---|---|
| Skin Material | Galvanized steel, galvanneal, aluminum, stainless steel |
| Thickness/R-Value | 2"/R10, 4"/R16, 6"/R20 |
| Max. Height | 20' |
| Finish | Mill, field paintable, powder coat |
| Fire Rating | ASTM E84 Class A |
| Specifications | Tongue-and-groove joint, Fully insulated joint, Structurally sound up to 18' free spans, Factory-cut and framed openings |
Product Overview
FläktGroup SEMCO AT Panel Systems include 2″, 4″, and 6″ thicknesses with a wide range of materials and performance offerings. SEMCO also offers a no-thru-metal panel system. The acoustic/thermal enclosures are suitable for a multitude of applications beyond standard built-up air handling units. Other applications include clean rooms, jet engine test cells, extended plenums, material handling enclosures, supply/return chase plenums, mixing plenums, data centers, and more.
For engineered performance, time savings, cost reduction, and simplified project management, build smarter with SEMCO Panel Solutions.
Key Features and Benefits
- Tongue-and-groove joint: Requires no screws in the joint, lessening installation time and leak potential
- Fully insulated joint: Reduces labor compared to field-insulated joints while ensuring acoustical and thermal performance
- Structurally sound: Allows for free span lengths up to 18 feet, reducing external steel required
- Factory-cut and framed openings: Decrease field labor
