Aurora IQSA Chilled Beam
Dimensionally designed to fit perfectly into standard 12″ ceiling grids, the Aurora IQSA delivers high cooling capacity while maintaining low air velocity and preserving the architectural integrity of the room.
Key Differentiators
- Perfect for narrow ceilings: Designed specifically for 1 ft. or 2 ft. ceiling grids, preserving architectural integrity
- High cooling capacity: Mixes ambient and supply air providing high cooling capacity with low air velocity
- Flexible airflow patterns: Patented energy control creates symmetrical or asymmetrical flows with screwdriver-only adjustment
- Easy access: Segmented perforated panels provide convenient access for cleaning, maintenance, and airflow pattern adjustment
- Energy efficient: Engineered for low operating and life-cycle costs with factory-mounted controls
- Seamless integration: Blend in with existing designs, thanks to available custom paint options that ensure beams are inconspicuous
- Made-in-America: Built with reliable, quality construction
Product Details
| Applications | Clean Rooms, Education, Government, Healthcare, Hospitality, Labs, Office and Commercial, Pharma |
|---|---|
| Length | 4.0' to 10.0' |
| Width | 1.0' |
| Operational Noise Levels | 40-70 dB |
| Nozzles | 0-36 mm |
| Coil Type | Water coil heating and/or cooling |
| Mount | Ceiling |
| Optional Accessories | Fastening bracket, drywall flange kit, cable suspension, purging nipple, and NEUTON Pump Module |
Product Overview
The Aurora IQSA is a narrow-profile active chilled beam designed for seamless integration into standard 12″ ceiling grids. Measuring just one foot wide and available in lengths from four to ten feet (in two-foot increments), this ceiling-mounted unit delivers efficient heating, cooling, and ventilation while maintaining architectural integrity in space-constrained applications.
Key Features and Benefits
- Ventilation, heating, and cooling
- Easily adjustable induction
- Both symmetrical and asymmetrical flow patterns
- Easy installation via fastening brackets or cable hanging
- Customizable paint options
- Condensation-free design: Proper latent-load control eliminates condensation risk and the need for drain pans, providing worry-free operation.
